TCQY seriyali baraban turi-tozalagich

Donlarni oldindan tozalash-

Ish sharoitlari

Jismoniy muhit

Harorat: -15-40 daraja

Nisbiy namlik: 90 foizdan oshmasligi kerak

Dengiz sathidan balandligi: 1,000m dan oshmasligi kerak

The working voltage should be stable, and deviation not more than ±5 percent .

Note: When the height above sea level exceeds 1,000m, the motor temperature will rise due to thin air, and when the temperature is lower than -15 degree , proper lubricating grease should be replaced.

 (4) Composition and meanings of the type

T C Q Y □ A

T---- Don va moyni qayta ishlash uchun universal uskunalar CQ----Old-tozalash Y----Baraban turi

□---Sieve drum diameter, mm A---Greatly modified one time

Oddiy tuzilish

Ease to clean and maintain.

Yordamchi tozalash uchun aspiratsiya tizimi

Ozuqa tegirmonlarida, don saqlash joylarida va hokazolarda materialni qabul qilish tizimida katta miqdordagi iflosliklarni olib tashlash uchun javob beradi.

Qo'llash va moslashuvchanlik

TCQY series drum pre-cleaner is widely used for raw materials receiving in flour mills, feed mills, depots and other industries. It is mainly used for removing large impurities as rice straw, wheat straw, hemp, sheet paper, clump, corn leaves, corn ear and etc., so as to protect the subsequent machines and equipments in the process system from damage.

Xususiyatlari

Bu baraban{0}}tozalagich yuqori quvvat, yaxshi tozalash effekti, kam quvvat sarfi, oddiy tuzilish, kichik maydon va boshqalar bilan ajralib turadi.

Uskunalar kirish eshigi bilan to'la bo'lib, u muntazam ta'mirlash va texnik xizmat ko'rsatish, shuningdek, elak tamburini almashtirish uchun qulaydir. Yon yuzada va yuqori qopqoqda ikkita kuzatuv oynasi jihozlangan, bu esa uskunaning ish holatini kuzatish imkonini beradi.

Appropriate sieve apertures can be selected as per the property of material, so as to get the optimum separation effect.

Ishlash printsipi

Xom ashyo elak barabaniga ish paytida kirish joyidan oziqlantiruvchi bunker orqali kiradi, elak barabani doimiy ravishda aylanadi, elakning teshiklaridan kichikroq geometrik o'lchamdagi tayyor mahsulot elak barabanidan tez o'tadi va chiqish joyidan oqib chiqadi. Elak teshiklaridan o‘ta olmaydigan katta aralashmalar elak barabanining ichki devoridagi yo‘naltiruvchi vintning kuchi bilan elak barabaridan, so‘ngra katta aralashmalar chiqarish joyidan chiqariladi. Qo'llanma vinti nafaqat katta aralashmalarni chiqarishga yordam beradi, balki materiallarning qoldiqlar bilan birga oqib chiqishini oldini oladi.

Texnik parametrlar
